Leuze HT25CI.XF/4P-M8 – Diffuse Sensor with Background Suppression, Series 25C
The Leuze HT25CI.XF/4P-M8 is a diffuse sensor with background suppression designed for reliable object detection in industrial automation systems. Part of the Leuze Series 25C family, this sensor uses the diffuse reflection principle with background suppression to detect objects while reducing the influence of background surfaces.
The sensor uses an infrared LED light source and provides stable detection of objects within its adjustable sensing range. Engineers commonly select this sensor for conveyor systems, packaging machinery, and automated material handling applications where consistent detection is required.
Key Features
- Diffuse reflection principle with background suppression
- Operating range from 40 mm to 500 mm on white 90% targets
- Operating range from 40 mm to 400 mm on black 6% targets
- Black-white error less than 10% up to 300 mm
- Adjustment range from 60 mm to 500 mm
- Infrared LED light source with 850 nm wavelength
- PNP transistor switching output with light switching principle
- 1,000 Hz switching frequency
- 0.5 ms response time
- Supply voltage: 10 to 30 V DC
- M8 4-pin male connector connection
- IP67 and IP69K protection ratings
- ECOLAB-compatible housing material
- Polarity reversal protection and short-circuit protection
- Certified to IEC 60947-5-2 with c UL US approval
Where This Sensor Is Used
The HT25CI.XF/4P-M8 is commonly used in food packaging, pharmaceutical machinery, conveyor systems, intralogistics applications, and automated production equipment. Its compact sensing range and background suppression technology help provide reliable object detection in industrial environments.
What's in the Box
Sensor unit only. Compatible M8 4-pin mating cable and optional mounting accessories must be ordered separately.
Buy from ProSens Automation
ProSens Automation is an authorized Leuze dealer based in Erode and Coimbatore region, Tamil Nadu, supplying genuine Leuze sensors across India. Every product comes with full manufacturer warranty. We provide technical support for sensor selection, wiring guidance, and commissioning help. Shipping available across India.
📱
WhatsApp us for price & availability—or tap the enquiry button above.
Frequently Asked Questions
What is the sensing range of the Leuze HT25CI.XF/4P-M8?
The sensor offers a guaranteed operating range from 40 mm to 500 mm on white 90% targets. For black 6% targets, the operating range is from 40 mm to 400 mm.
Is the HT25CI.XF/4P-M8 suitable for demanding industrial environments?
Yes. The sensor carries IP67 and IP69K protection ratings and uses ECOLAB-compatible materials. It operates in ambient temperatures from -40 °C to 60 °C and complies with IEC 60947-5-2 standards.
What accessories are required for installation?
The package includes the sensor unit only. A compatible M8 4-pin mating cable and optional mounting hardware must be ordered separately.
