Product Description
Leuze HT46C-4P-M12 – Diffuse Sensor with Background Suppression, Series 46C
The Leuze HT46C-4P-M12 is a diffuse reflection sensor with background suppression from the Series 46C family. It is designed for reliable object detection regardless of object colour while minimizing unwanted background reflections. Using the diffuse reflection principle with background suppression, the sensor delivers stable switching performance in demanding industrial automation applications.
Key Features
- Diffuse reflection principle with background suppression
- Series 46C compact optical sensor
- Operating range: 5…400 mm
- Red LED light source, 660 nm wavelength
- PNP transistor output (Light ON / Dark ON)
- Switching frequency: 1,000 Hz
- Response time: 0.5 ms
- Supply voltage: 10…30 VDC
- 4-pin M12 male connector
- Die-cast zinc housing with plastic front, IP67/IP69K protection, ECOLAB approved and cULus certified
Where This Sensor Is Used
The HT46C-4P-M12 is suitable for conveyor systems, packaging machinery, food processing equipment, pharmaceutical production, textile machinery, automotive assembly and material handling applications. It provides dependable object detection where varying object colours and backgrounds are encountered.
What's in the Box
Sensor unit only. A compatible 4-pin M12 female connection cable must be ordered separately.
Buy from ProSens Automation
ProSens Automation is an authorized Leuze dealer based in Erode and Coimbatore region, Tamil Nadu, supplying genuine Leuze sensors across India. Every product comes with full manufacturer warranty. We provide technical support for sensor selection, wiring guidance, and commissioning help. Shipping available across India.
📱WhatsApp us for price & availability—or tap the enquiry button above.
Frequently Asked Questions
What is the sensing range of the HT46C-4P-M12?
The sensor provides a sensing range from 5 mm to 400 mm with background suppression. It delivers reliable detection of objects with different colours and surface finishes.
Can this sensor be used in harsh industrial environments?
Yes. The sensor features IP67 and IP69K protection, ECOLAB approval and operates from -40°C to +60°C, making it suitable for demanding industrial environments.
What is included with the sensor?
The package contains the sensor unit only. A compatible 4-pin M12 female connection cable should be ordered separately.
Where can I buy the Leuze HT46C-4P-M12 in India?
ProSens Automation is an authorized Leuze dealer in Erode and Coimbatore region, Tamil Nadu. We supply genuine Leuze products across India with full manufacturer warranty. WhatsApp us for pricing and delivery timeline.
