Leuze HT46CI-4P – Diffuse Sensor with Background Suppression, Series 46C
The Leuze HT46CI-4P is a diffuse reflection sensor with background suppression from the Series 46C family. It uses infrared light to provide reliable object detection with minimal influence from object colour and ambient light. The diffuse reflection principle with background suppression ensures accurate switching while suppressing unwanted background reflections in demanding industrial applications.
Key Features
- Diffuse reflection principle with background suppression
- Series 46C compact optical sensor
- Operating range: 5…250 mm
- Infrared LED light source, 880 nm wavelength
- PNP transistor output (Light ON / Dark ON)
- Switching frequency: 1,000 Hz
- Response time: 0.5 ms
- Supply voltage: 10…30 VDC
- Integrated 2 m PUR cable connection
- Die-cast zinc housing with glass front, IP67/IP69K protection, ECOLAB approved and cULus certified
Where This Sensor Is Used
The HT46CI-4P is ideal for conveyor systems, packaging machinery, food processing equipment, pharmaceutical production, textile machinery, automotive assembly and material handling systems. Its infrared operating principle provides dependable object detection for products with different colours and surface finishes.
What's in the Box
Sensor unit with integrated 2 m PUR cable.
Buy from ProSens Automation
ProSens Automation is an authorized Leuze dealer based in Erode and Coimbatore region, Tamil Nadu, supplying genuine Leuze sensors across India. Every product comes with full manufacturer warranty. We provide technical support for sensor selection, wiring guidance, and commissioning help. Shipping available across India.
📱WhatsApp us for price & availability—or tap the enquiry button above.
Frequently Asked Questions
What is the sensing range of the HT46CI-4P?
The sensor provides an operating range from 5 mm to 250 mm using infrared light with background suppression. It delivers reliable detection of objects while minimizing interference from background surfaces.
Can this sensor be used in harsh industrial environments?
Yes. The HT46CI-4P is rated IP67 and IP69K, operates from -40°C to +60°C, and features an ECOLAB-approved housing suitable for demanding industrial environments.
What is included with the sensor?
The package includes the sensor with an integrated 2 m PUR cable. No additional connection cable is required.
